| High Light: | Slit Lamp ophthalmic surgical microscope,electromagnetic ophthalmology surgical microscope,Lock Easy Surgical Operating Microscope |
||
|---|---|---|---|
Features
Optics Lens
| The material of the optics lens on the instrument are imported from Schott Glass Technologies, the surfaces have multi-layer coating and high transparency, the image is clear and bright,the lens have long service life |
6°±2°Coaxial Illumination
| Use the 6°±2°coaxial illumination technology , has better illumination and bigger area of red-reflex , the back capsule of the lens is more clear during the operation period. |
Multi-layer Filters
| The illumination system equipped multi-layer filters, UV,IR filters are used to arrest the heat energy; and also has yellow spot protecting filter,redfree filter,illumination damage prevented filter etc. |
Electromagnetic Lock
| Electromagnetic lock and balance technology ensure the easy operation and stable orientation. |
Optional Accessories
| Aspherics and BIOM added on objective could meet the demands of vitreo-retinal operations. |
Delicacy and Massiness
| The modeling line of the instrument is smooth, both the mechanical parts and the optical systems are well designed. Not only the balance arm and the motive base are massive, but the art of the combination of function and beauty. |
| The instrument adobe the space balance technique, both the microscope part and the balance arm can be moved easily to any directions. |
Specifications
|
Main microscope |
|
|
Total magnification(main) |
4.6×~27× |
|
Diameter of visual field(mm) |
8.5~46 |
|
Assistant microscope |
|
