| Place of Origin: | CHINA |
| Brand Name: | 66 VISION |
| Certification: | CE FDA |
| Model Number: | YZ5F |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton |
| Delivery Time: | one week |
| Supply Ability: | 2000/year |
| High Light: | ophthalmology slit lamp,ophthalmic slit lamp |
||
|---|---|---|---|
Characteristics:
· Converging stereoscope microscope provides the clear images.
· Imported Schott optics from Germany reduces optical distortion, increases clarity and depth of focus.
· All the optical lenses are moistureproof, mildewproof and anti-reflected treated.
· Three-step magnifications (10X,16X,25.6X) can be changed by lever and 10X&16X eyepieces are available.
· All the joints can be connected by accessories with international standards.
Specificatiions:
| Microscope Type | Converging stereoscope microscope |
| Objective Magnification | Two Steps Magnifications |
| Eyepiece | 10x and 16x |
|
Magnifications (Field of View) |
10x(φ18mm),16x(φ14.5mm) 16x(φ11.25mm),25.6x(φ9mm) |
| Pupil Distance |
10x Eye Piece 55mm～82mm 16x Eye Piece 51mm～78mm |
| Diopter Adjustment |
10x Eye Piece ±8D 16x Eye Piece ±10D |
| Slit Width | 0mm～9mm adjustable(Slit is round when the slit width is 9mm) |
| Slit Height | 1mm～8mm adjustable |
| Slit Angle | 0°～180°adjustable |
| Slit Inclination | 5°,10°,15°,20°,four steps adjustable |
| Diameter of Light Spot | φ9mm,φ8mm,φ5mm,φ3mm,φ2mm,φ1mm,φ0.2mm |
| Filter | Heat Absorption,Grey,Redfree,Cobalt Blue |
| Illumination Bulb | 12V/30W Halogen Bulb |
